Product informations

Voltage: DC 5V  7- 32 V

Control Mode: From App eWelink

Mode of transport: Wifi

System: for Android ,for IOS

Wifi Work Frequency: 2.4G 802.11 b / g / n

Power Power Consumption of Rest: 80mA; if all relays are up, max 380mA

1-Channel Switch:≤ 10A (Nominal Current ); voltage switch: ≤ 250 V

Insulation Resistance: 100 M ohm

Electric Shock Maximum Voltage: 1000 V

Relay Max Operating Time: 15 ms

Relay Max Release Time: 5 ms

Operating Temperature: 0 ~ 60 °

Operating Humidity: 40% -80% RH

With Signal Indicator Lamp Relay Operation Lamp

4 Pcs 10A Relays

Size: 75 * 73 * 25mm

Max power :10A/2200W
